Seagate BarraCuda 2.5-Inch Internal Solid State Drives (SSD)
Perfect for optimizing performance, capacity, and speed of PCs and laptops

Overview:

Speed Up Your Computer.

Take your data to the next level of performance, reliability, and efficiency with one of our Seagate BarraCuda solid state drives.

BarraCuda solid state drives come in both 2.5 SATA form factors, perfect for ultra thin and ultra small laptops, mini PCs, and desktop PCs that need next-level SSD speed for accelerated applications and multitasking.

Key Advantages

• Soar to new heights of performance with Seagate BarraCuda SSD providing maximum sequential read and write speeds, reaching 560/540MB/s.
• Unmatched Dependability–the new Seagate BarraCuda SSD is a cost-effective way to handle all your PC needs—working, playing, storing your movies and music, and more.
• Amazing versatility with spacious capacity options up to 2TB lets you stay in the flow no matter how much heavy lifting and multitasking is on your plate.
• SATA 6Gb/s interface for optimal performance and compatibility with your PC or laptop.

Best-Fit Applications

• Desktop or all-in-one PCs
• Laptops
• Home servers

Features:

SATA Gives You a Boost.

¹ Rescue Data Recovery Services plans are not available in all countries. Please contact your Seagate sales representative for further details.

Specifications:

Specifications	2TB	1TB	500GB	250GB
Standard Model Number	ZA2000CM10002	ZA1000CM10002	ZA500CM10002	ZA250CM10002
Features
Interface	SATA 6Gb/s	SATA 6Gb/s	SATA 6Gb/s	SATA 6Gb/s
NAND Flash Type	3D TLC	3D TLC	3D TLC	3D TLC
Form Factor	2.5 in × 7mm	2.5 in × 7mm	2.5 in × 7mm	2.5 in × 7mm
Performance
Sequential Read (Max, MB/s), 128KB1,2	560	560	560	560
Sequential Write (Max, MB/s), 128KB1,2	540	540	535	530
Random Read (Max, IOPS), 4KB QD321,2	90,000	90,000	90,000	90,000
Random Write (Max, IOPS), 4KB QD321,2	90,000	90,000	90,000	90,000
Endurance/Reliability
Total Bytes Written (TB)	1067	485	249	120
Mean Time Between Failures (MTBF, hours)	1,800,000	1,800,000	1,800,000	1,800,000
Limited Warranty (years)	5	5	5	5
Power Management
Active Power, Average (W)	3.1	2.8	2.6	2.6
Idle Power, Average (mW)	225	221	192	185
DevSleep (mW)	5	5	5	5
Environmental/Temperature
Temperature, Operating Internal (°C)	0 to 70°C	0 to 70°C	0 to 70°C	0 to 70°C
Temperature, Nonoperating (°C)	–40 to 85°C	–40 to 85°C	–40 to 85°C	–40 to 85°C
Shock, Nonoperating: 0.5ms (Gs)	1500	1500	1500	1500
Physical
Height (mm)	7.00mm	7.00mm	7.00mm	7.00mm
Width (mm)	69.85mm	69.85mm	69.85mm	69.85mm
Depth (mm)	100.00mm	100.00mm	100.00mm	100.00mm
Weight (g)	50g	50g	50g	50g
Special Features
TRIM	Yes	Yes	Yes	Yes
S.M.A.R.T.	Yes	Yes	Yes	Yes
Halogen Free	Yes	Yes	Yes	Yes
RoHS Compliance	Yes	Yes	Yes	Yes
System Requirements
System Requirements	SATA 6Gb/s or SATA 3Gb/s port, Windows 10, Windows 8.1 or Windows 7, Linux

¹ Fresh out of box (FOB) performance obtained on newly formatted drive. Performance may vary based on SSD’s firmware version, system hardware, and configuration.
² Performance based on CrystalDiskMark v.5.2.1 ×64 on Windows 10 host.

Views:

Documentation:

Download the Seagate BarraCuda 2.5-Inch Internal SSD Datasheet (.PDF)
