Seagate Nytro® 3732 SAS Solid State Drives (SSD)
Built For Fast Data Center Applications

Overview:

Key Features and Benefits

• 12Gb/s SAS interface and dual ports for 24×7 performance
• High-density capacities of up to 15TB in a 2.5-in × 15mm form factor
• Low latency and high QoS for better responsiveness and user experience
• Easily manage and monitor SSD health with SeaChest
• Three endurance options to meet workload, deployment, and TCO demands
• Ensures reliable data protection for mission-critical applications
• Seagate Secure™ with Secure Download and Diagnostics (SD&D), SED, and SED FIPS 140-2 options for advanced data security¹
• Built for easy integration with Linux and Microsoft OS

Best-Fit Applications

• Server virtualization
• OLTP databases
• Software-defined storage
• All-flash arrays
• Caching and tiering

1 Self-encrypting drives (SED) are not available in all models or countries. May require TCG-compliant host or controller support

Specifications:

Specifications	Nytro 3732 — Write Intensive
Capacity	3.2TB	1.6TB	800GB	400GB
Standard Model Number	XS3200ME70084	XS1600ME70084	XS800ME70084	XS400ME70084
Seagate Secure™ SED Model1	XS3200ME70094	XS1600ME70094	XS800ME70094	XS400ME70094
Seagate Secure FIPS 140-2/Common Criteria Model1	XS3200ME70104	XS1600ME70104	—	—
Seagate Instant Secure Erase (ISE) Model	XS3200ME70114	XS1600ME70114	XS800ME70114	XS400ME70114
Features
Interface (Dual Port)	12 Gb/s SAS	12 Gb/s SAS	12 Gb/s SAS	12 Gb/s SAS
NAND Flash Type	3D eTLC	3D eTLC	3D eTLC	3D eTLC
Form Factor	2.5 in × 15mm	2.5 in × 15mm	2.5 in × 15mm	2.5 in × 15mm
Performance—Single Port 12Gb\s
Sequential Read (MB/s) Sustained,128KB2	1100	1100	1100	1100
Sequential Write (MB/s) Sustained, 128KB2	1000	1000	1000	950
Random Read (IOPS) Sustained, 4KB2	170,000	180,000	180,000	170,000
Random Write (IOPS) Sustained, 4KB2	200,0000	200,0000	200,0000	200,0000
Random 30% Write (IOPS) Sustained, 4KB2	190,000	190,000	190,000	180,000
Performance—Dual Port 12Gb\s
Sequential Read (MB/s) Sustained,128KB2	2200	2200	2200	2150
Sequential Write (MB/s) Sustained, 128KB2	1650	1650	1650	1300
Random Read (IOPS) Sustained, 4KB 2	240,000	240,000	220,000	200,000
Random Write (IOPS) Sustained, 4KB 2	200,000	200,000	200,000	200,000
Random 30% Write (IOPS) Sustained, 4KB 2	260,000	260,000	250,000	200,000
Endurance/Reliability
Lifetime Endurance (Drive Writes per Day)	10	10	10	10
Total Bytes Written (TB)	58,400	29,200	14,600	7300
Nonrecoverable Read Errors per Bits Read	1 per 10E17	1 per 10E17	1 per 10E17	1 per 10E17
Annualized Failure Rate (AFR)	0.35%	0.35%	0.35%	0.35%
Warranty, Limited (years)	5	5	5	5
Power Management
+5/+12V Max Start Current (A)	0.80/0.21	0.80/0.21	0.80/0.21	0.80/0.21
Average Idle Power (W)	4.6	4.6	4.6	4.6
Physical
Height (in/mm, max)3	0.591in/15.00mm	0.591in/15.00mm	0.591in/15.00mm	0.591in/15.00mm
Width (in/mm, max)3	2.760in/70.10mm	2.760in/70.10mm	2.760in/70.10mm	2.760in/70.10mm
Depth (in/mm, max)3	3.955in/100.45mm	3.955in/100.45mm	3.955in/100.45mm	3.955in/100.45mm
Weight (lb/g)	0.364lb/165g	0.364lb/165g	0.364lb/165g	0.364lb/165g
Carton Unit Quantity	10	10	10	10
Cartons per Pallet	90	90	90	90
Cartons per Layer	9	9	9	9

¹ Not all drives may be available in all countries. Seagate Secure drives meet ISO/IEC 27040 and NIST 800-88 standards and may require use of TCG-compliant host or controller support.
² All performance measured at queue depth of 32 per PHY at beginning of life. System application performance may vary based on SAS host and prior system workload.
³ These base deck dimensions conform to the Small Form Factor Standard (SFF-8201) found at www.sffcommittee.org. For connector-related dimensions, see SFF-8223 (SAS models).

Documentation:

Download the Seagate® Nytro® 3032 SAS SSD Series Datasheet (.PDF)
