Overview:
The Maxtor® Z1 2.5-inch internal SSD provides up to 960GB of storage to bring your desktop and laptop applications to life with faster system boots, loads, and transfer times.
- Take your desktop or laptop to the next level with the performance you need at a fraction of the cost
- Increased durability with robust shock and vibrational resistance (1500G/.5ms)
- 3-year limited warranty and 1.2M-hr MTBF for peace of mind
- Upgrade lagging laptop and desktop systems with plug-and-play standard 2.5-inch
- SATA form factor
- Improve existing system performance with high sequential read/write speeds (540MB/sec and 475MB/sec, respectively)
- Power-efficient drive uses only up to 2.2W in active power
- Be mobile longer with extended battery life in laptops and portable devices
Specifications:
|
Specifications
|
960GB
|
480GB
|
240GB
|
|
Standard Model
|
YA960VC10001
|
YA480VC10001
|
YA240VC10001
|
|
Interface1
|
SATA 6Gb/s
|
SATA 6Gb/s
|
SATA 6Gb/s
|
|
Form Factor
|
2.5 in × 7mm
|
2.5 in × 7mm
|
2.5 in × 7mm
|
|
Performance
|
|
Sequential Read (Max, MB/s), 128KB2
|
540
|
540
|
540
|
|
Sequential Write (Max, MB/s), 128KB2
|
475
|
465
|
425
|
|
Endurance/Reliability
|
|
Total Bytes Written (TB)
|
360
|
180
|
90
|
|
Mean Time Between Failures (MTBF, hours)
|
1,200,000
|
1,200,000
|
1,200,000
|
|
Warranty, Limited (years)
|
3
|
3
|
3
|
|
Power Management
|
|
Active Power, Average (W)
|
2.2
|
2.0
|
1.97
|
|
Slumber (mW)
|
16
|
16
|
16
|
|
Environmental
|
|
Temperature, Operating Internal (°C)
|
0 to 70
|
0 to 70
|
0 to 70
|
|
Temperature, Nonoperating (°C)
|
–40 to 85
|
–40 to 85
|
–40 to 85
|
|
Shock, Nonoperating: 0.5ms (Gs)
|
1500
|
1500
|
1500
|
|
Special Features
|
|
TRIM
|
Yes
|
Yes
|
Yes
|
|
S.M.A.R.T.
|
Yes
|
Yes
|
Yes
|
|
Halogen Free
|
Yes
|
Yes
|
Yes
|
|
RoHS Compliance
|
Yes
|
Yes
|
Yes
|
|
Physical
|
|
Height (mm/in)
|
7.00mm/0.276in
|
7.00mm/0.276in
|
7.00mm/0.276in
|
|
Width (mm/in)
|
69.85mm/2.75in
|
69.85mm/2.75in
|
69.85mm/2.75in
|
|
Depth (mm/in)
|
100.20mm/3.945in
|
100.20mm/3.945in
|
100.20mm/3.945in
|
|
Weight (g/lb)
|
36g/0.079lb
|
36g/0.079lb
|
36g/0.079lb
|
1 Performance data is based on testing under certain workload conditions and is subject to change. Performance assumes that a typical enterprise data workload has 80% entropy.
2 3.84TB, 1.92TB, and 960GB capacity points require 12V in addition to 5V power.
Documentation:
Download the Seagate Maxtor 2.5" SSD Datasheet (.PDF)
