Overview:
Speed Up Your Computer.
Take your data to the next level of performance, reliability, and efficiency with one of our Seagate BarraCuda solid state drives.
BarraCuda solid state drives come in both 2.5 SATA form factors, perfect for ultra thin and ultra small laptops, mini PCs, and desktop PCs that need next-level SSD speed for accelerated applications and multitasking.
Key Advantages
- Soar to new heights of performance with Seagate BarraCuda SSD providing maximum sequential read and write speeds, reaching 560/540MB/s.
- Unmatched Dependability–the new Seagate BarraCuda SSD is a cost-effective way to handle all your PC needs—working, playing, storing your movies and music, and more.
- Amazing versatility with spacious capacity options up to 2TB lets you stay in the flow no matter how much heavy lifting and multitasking is on your plate.
- SATA 6Gb/s interface for optimal performance and compatibility with your PC or laptop.
Best-Fit Applications
- Desktop upgrades
- HDD or SSD swap-out upgrades
- Laptop upgrades
Features:
SATA Gives You a Boost.
Advanced Speed
Use an internal laptop SSD that is up to 30× faster than traditional HDD.
Coveted Versatility
Enjoy easy plug-and-play installation for upgrading.
Proven Reliability
Take advantage of a 5-year limited warranty.
Benefit From SeaTools
SeaTools SSD is our free software that tests and analyzes drives. It is completely data safe and easily installs on your system.
Use it for:
- Health Monitoring
- Drive Maintenance
- Overall Monitoring
Insure Your Drive
A Rescue Data Recovery Services plan is available for purchase when you register your BarraCuda drive.1 You’ll have access to a global team of world-class data recovery experts in case of unexpected data loss.
1 Rescue Data Recovery Services plans are not available in all countries. Please contact your Seagate sales representative for further details.
Specifications:
Specifications |
2TB |
1TB |
500GB |
Standard Model |
ZP2000CV30001 |
ZP1000CV30001 |
ZP500CV30001 |
Interface |
PCIe® Gen3 ×4 NVMe™ 1.3 |
PCIe Gen3 ×4 NVMe 1.3 |
PCIe Gen3 ×4 NVMe 1.3 |
NAND Flash Memory |
3D QLC |
3D QLC |
3D QLC |
Form Factor |
M.2 2280-S2 |
M.2 2280-S2 |
M.2 2280-S2 |
Performance |
Sequential Read (Max, MB/s), 128KB1 |
2400 |
2400 |
2300 |
Sequential Write (Max, MB/s), 128KB1 |
1800 |
1700 |
900 |
Endurance/Reliability |
Total Bytes Written (TB) |
531 |
274 |
119 |
Mean Time Between Failures (MTBF, hours) |
1,800,000 |
1,800,000 |
1,800,000 |
Warranty, Limited (years) |
3 |
3 |
3 |
Rescue Data Recovery Services (years) |
1 |
1 |
1 |
Power Management |
Active Power, Average (W) |
3.3 |
3.1 |
2.2 |
Idle Power PS3, Average (mW) |
25 |
27 |
23 |
Low Power L1.2 mode (mW) |
1.6 |
1.6 |
1.5 |
Environmental |
Temperature, Operating Internal (°C) |
0 to 70 |
0 to 70 |
0 to 70 |
Temperature, Nonoperating (°C) |
–40 to 85 |
–40 to 85 |
–40 to 85 |
Shock, Nonoperating: 0.5ms (Gs) |
1500 |
1500 |
1500 |
Special Features |
TRIM |
Yes |
Yes |
Yes |
S.M.A.R.T. |
Yes |
Yes |
Yes |
Halogen Free |
Yes |
Yes |
Yes |
RoHS Compliance |
Yes |
Yes |
Yes |
Physical |
Height (mm/in, max) |
2.15mm/0.084in |
2.15mm/0.084in |
2.15mm/0.084in |
Width (mm/in, max) |
22.00mm/0.866in |
22.00mm/0.866in |
22.00mm/0.866in |
Depth (mm/in, max) |
80.00mm/3.149in |
80.00mm/3.149in |
80.00mm/3.149in |
Weight (g/lb) |
7g/0.015lb |
7g/0.015lb |
7g/0.015lb |
1 Fresh out of box (FOB) performance obtained on newly formatted drive. Performance may vary based on SSD’s firmware version, system hardware, and configuration.
2 Performance based on CrystalDiskMark v.5.2.1 ×64 on Windows 10 host.
